Product Details:
|
Application: | Suitable For Conveying Media Such As Water And Hydraulic Oil Under High Pressure, Widely Used In Industries Such As High Pressure Cleaning | Inner Tube: | Nylon |
---|---|---|---|
Reinforcement: | Four Layers Of High-strength Ultra-flexible Steel Wire Winding | Outer Layer: | Oil-resistant, Aging-resistant, Weather-resistant Black Polyurethane |
Temperature Range: | -40℃ ~ +100℃(-40℉ ~ +212℉) | Name: | Ultra High Pressure Resin Hose |
High Light: | 150Mpa High Pressure Hose Pipe,12.7mm Hose Pipe High Pressure,150Mpa Hose Pipe High Pressure |
Application: Suitable for conveying media such as water and hydraulic oil under high pressure, widely used in industries such as high pressure cleaning
Inner Tube: nylon
Reinforcement: Four-layer or six-layer high-strength ultra-flexible steel wire winding
Outer Layer: Oil-resistant, aging-resistant, weather-resistant black polyurethane
Temperature Range: -40℃ ~+100℃(-40℉ ~ +212℉)
Parameter
I.D. | O.D. | W.P. | W.P. | MIN.B.P. | W.T. | ||||
Dash | In. | mm | mm | MPa | psi | MPa | psi | mm | g/m |
-3 | 3/16 | 4.8 | 13.5 | 150 | 21750 | 450 | 65250 | 200 | 450 |
-4 | 1/4 | 6.3 | 14.8 | 150 | 21750 | 450 | 65250 | 220 | 530 |
-5 | 5/16 | 7.9 | 16.4 | 150 | 21750 | 450 | 65250 | 250 | 640 |
-6 | 3/8 | 9.5 | 20.4 | 150 | 21750 | 450 | 65250 | 250 | 1000 |
-8 | 1/2 | 12.7 | 23.6 | 150 | 21750 | 450 | 65250 | 300 | 1180 |
