Product Details:
|
| Application: | Suitable For Conveying Media Such As Water And Hydraulic Oil Under High Pressure, Widely Used In Industries Such As High Pressure Cleaning | Inner Tube: | Nylon |
|---|---|---|---|
| Reinforcement: | Four Layers Of High-strength Ultra-flexible Steel Wire Winding | Outer Layer: | Oil-resistant, Aging-resistant, Weather-resistant Black Polyurethane |
| Temperature Range: | -40℃ ~ +100℃（-40℉ ~ +212℉） | Name: | Ultra High Pressure Resin Hose |
| High Light: | 29000PSI High Pressure Cleaning Hose,3 16 inch High Pressure Cleaning Hose |
||
Application: Suitable for conveying media such as water and hydraulic oil under high pressure, widely used in industries such as high pressure cleaning
Inner Tube: nylon
Reinforcement: Four-layer or six-layer high-strength ultra-flexible steel wire winding
Outer Layer: Oil-resistant, aging-resistant, weather-resistant black polyurethane
Temperature Range: -40℃ ~+100℃(-40℉ ~ +212℉)
Parameter
| I.D. | O.D. | W.P. | W.P. | MIN.B.P. | W.T. | ||||
| Dash | In. | mm | mm | MPa | psi | MPa | psi | mm | g/m |
| -3 | 3/16 | 4.8 | 14.5 | 200 | 29000 | 600 | 87000 | 220 | 600 |
| -4 | 1/4 | 6.3 | 16.4 | 200 | 29000 | 600 | 87000 | 250 | 800 |
| -6 | 3/8 | 9.5 | 21.2 | 200 | 29000 | 600 | 87000 | 300 | 1300 |
| -8 | 1/2 | 12.7 | 25 | 200 | 29000 | 600 | 87000 | 320 | 1600 |
