Product Details:
|
| Tube: | Black Conducive NBR | Applications: | For Suction And Discharge Applications In Truck And Tank Car Transfer Of Gasoline, Oil And Other Petroleum-based Products With Up To 50% Aromatic Content |
|---|---|---|---|
| Cover: | Black CR-abrasion, Ozone And Hydrocarbon Resistant | Working Pressure: | Constant Pressure-10Bar(150PSI) |
| Temperature Range: | -30℃(-22°F)to +80℃(+176°F) | Reinforcement: | High Tensile Textile Cords And High Flexible Steel Helix Wires |
| High Light: | 3/4" Oil Fuel Hose,8" Oil Fuel Hose,8" Petroleum S&D Hose |
||
| Specifications | ||||||||
| Series | I.D. (in.) | I.D. (mm) | O.D. (in.) | O.D. (mm) | Max.W.P.(psi) | Vacuum HG (in.) | Min.B.R. (mm) | W. (kg/m) |
| LT1210-075 | 3/4 | 19 | 1.14 | 29 | 150 | 30 | 3 | 0.61 |
| LT1210-100 | 1 | 25 | 1.38 | 35 | 150 | 30 | 4 | 0.77 |
| LT1210-125 | 11/4 | 32 | 1.65 | 42 | 150 | 30 | 5 | 0.91 |
| LT1210-150 | 11/2 | 38 | 1.89 | 48 | 150 | 30 | 6 | 1.06 |
| LT1210-200 | 2 | 51 | 2.40 | 61 | 150 | 30 | 8 | 1.35 |
| LT1210-250 | 21/2 | 63 | 2.95 | 75 | 150 | 27 | 10 | 2.11 |
| LT1210-300 | 3 | 76 | 3.46 | 88 | 150 | 27 | 12 | 2.53 |
| LT1210-400 | 4 | 102 | 4.57 | 116 | 150 | 27 | 16 | 3.51 |
| LT1210-600 | 6 | 152 | 6.61 | 168 | 150 | 24 | 24 | 7.37 |
| LT1210-800 | 8 | 203 | 8.70 | 221 | 150 | 21 | 32 | 11.71 |
Competitive Advantage:
