Product Details:
|
| Brand: | LETONE | Inner Layer: | PTFE |
|---|---|---|---|
| Reinforcement Layer: | Synthetic Fiber And Spiral Steel Wire | Outer Layer: | EPDM / FKM |
| Temperature Range: | -30 ℃ ~ + 220 ℃ (-22 ℉ ~ + 428 ℉) | Reference Standard: | EN12115 |
| High Light: | PTFE Chemical Resistant Hose,Multifunctional Chemical Resistant Hose,PTFE low pressure hose |
||
LT401L PTFE low-pressure multifunctional industrial hose
Chemical Hose
Our rubber chemical hoses are specifically manufactured for the transfer of harsh chemicals and media, conveying liquids such as organic and inorganic acids, ketones, paints, esters and aromatic and aliphatic hydrocarbons (dependent on the liner). All types are highly suitable for external applications due to their EPDM outer cover, providing excellent resistance to ozone and weathering. Our UHMW hoses also comply with FDA regulations, making them suitable for use with foodstuffs such as animal and vegetable oils, while the EPDM options are manufactured from an electrically conductive, anti-static rubber compound.
Application: Widely used in chemical, steel, construction, food, medicine and other fields. The product is suitable for high temperature working environment. Its super corrosion resistance makes it free from various corrosive liquid chemicals (sulfuric acid, Hydrochloric acid, sulfur reactants, etc.) erosion. The fully saturated nature of PTFE / PFA also makes it a good choice for tubes in the food and pharmaceutical industries
Inner layer: PTFE
Reinforcement layer: synthetic fiber and spiral steel wire
.Outer layer: EPDM / FKM
Temperature range: -30 ℃ ~ + 220 ℃ (-22 ℉ ~ + 428 ℉)
Reference standard: EN12115
Parameter
| SIZE | I.D. | W.P. | B.P. |
| (in.) | (mm) | (MPa) | (MPa) |
| 3/4" | 19 | 1.6 | 6.4 |
| 1" | 25 | 1.6 | 6.4 |
| 1-1/4" | 32 | 1.6 | 6.4 |
| 1-1/2" | 38 | 1.6 | 6.4 |
| 2" | 51 | 1.6 | 6.4 |
| 2-1/2" | 64 | 1.6 | 6.4 |
| 3" | 76 | 1.6 | 6.4 |
| 3-1/2" | 89 | 1.6 | 6.4 |
| 4" | 102 | 1.6 | 6.4 |
