1 Inch Super Artery Letone Hydraulic Hose 92MPa Long Service Life

Braided Hoses
The structure of the braided hose is assembled by interlocking steel in a criss-cross formation, like a metal cloth. The best feature of the braided hose is that it offers greater flexibility due to its lower bend radius (the degree at which a hose can bend back on itself). This presents better practicality when the hose must operate in a tight spaced hydraulic system. The wire braided hose are manufactured for medium & high pressures, and can be made stronger with additional bands, referred to as one-wire hoses, two-wire hoses etc.
The downside to the wire braided hose it that it does not cope with high-impulse applications – rapid pulses in the systems’ pressure over a short period of time, like in a jackhammer. This expansion & contraction separates the braids over time. This process can also cause the braids to become hot as the overlapping wires create friction, thus putting the hose in risk of failure and a shorter life span.
Applications: It is suitable for the transportation of water-based, petroleum-based hydraulic oil and biodegradable hydraulic oil in harsh working environments such as excavators and other construction machinery, construction machinery, mining machinery and agricultural machinery.
Tube: CR/NBR synthetic rubber
Reinforcement: braided high tensile super fexible steel wire, one braid impulse reaches 300,000 cycles, two braids reaches 600,000 cycles
OuterLayer: skiving-free black smooth hose cover made of anti aging synthetic rubber
Low bending radius: 30% lower than SAE/DIN standards
High pressure: 30% higher than SAE/DIN standards
Long service life: weather resistant for more than 5 years and warrantied for 2years (with Letone specific hoseconnectors)
