Product Details:
|
Features: | Small Volume Expansion Under Pressure | Application: | Used In Very High Pressure Application Environment, Such As Cleaning The Inner Tube Of Heat Exchanger In Industries Such As Chemical And Oil Refining |
---|---|---|---|
Pressure Range: | 690~1200 Bar (10000 ~ 17400 Psi) | Joint: | Optional With Integrated Cartilage Dry Joint |
High Light: | 2S High Pressure Cleaning Hose,3/16 Inch High Pressure Cleaning Hose,1/4 Inch hydro jetting hose |
A spiral wound hose consists of two or more sets of helically wrapped high-tensile wire that exhibits exemplary strength, making the hose very strong but also very rigid. The resistance to pressure spikes is exceptionally high, especially compared to a braided hose. However, the bend radius suffers, and spiral wound hose is highly resistant to bending. This effect is especially pronounced with 4- or 6-wire hoses, which are required from many large diameter, high-pressure applications.
Part number | Hose size | ID | OD | WP | |||||
dash | inch | DN | mm | inch | mm | inch | bar | psi | |
2S-3-1040 | -2 | 1/8 | 3 | 3.5 | 0.138 | 7.2 | 0.283 | 1040 | 15000 |
2S-4-1200 | - | 5/32 | 4 | 4.1 | 0.161 | 8.2 | 0.323 | 1200 | 17400 |
2S-5-1040 | -3 | 3/16 | 5 | 5.2 | 0.205 | 9.8 | 0.386 | 1040 | 15000 |
2S-6-1040 | -4 | 1/4 | 6 | 6.4 | 0.252 | 11.5 | 0.453 | 1040 | 15000 |
2S-8-1040 | -5 | 5/16 | 8 | 7.9 | 0.311 | 13.7 | 0.539 | 1040 | 15000 |
2S-10-690 | -6 | 3/8 | 10 | 9.9 | 0.390 | 16.4 | 0.646 | 690 | 10000 |
2S-12-690 | -8 | 1/2 | 12 | 12.8 | 0.504 | 20.4 | 0.803 | 690 | 10000 |
