Product Details:
|
| Tube: | NR&SBRsythentic Rubber/HNBR/UPE | Reinforcement: | 4 Or 6 Layers Of High Tensile Super Flexible Spiral Steel Wire Or Steel Cable |
|---|---|---|---|
| Cover: | Abrasion And Weather Resistant Synthetic Rubber | Temperature Range: | -20°C~+82°C (-4°F〜+179.6°F) |
| Standard: | API Spec. 7K FSL0 | ABS | Connectors: | Integral Union Or Integral Flange |
| High Light: | 1500psi Concrete Vibrator Hose,Integral Union Rotary Drill Hose,1500psi Rotary Hose In Drilling Rig |
||
The drilling hoses have found their wide application in the extraction of minerals such as oil, and gas. With the help of the drill pipe, a drilling mud is injected into the well at a very high pressure, most often technical water, hydrogel solution or clay-based solutions. The drill hose is also used between oil tankers and drilling wells in the sea. Drilling hoses can be used on stationary and mobile drilling rigs, for drilling wells in the sea.
The hose for drilling is also used for damping vibrations of rotary plants. In this case, it is made of small length and serves as a compensator.
Parameter:
| PRESSURE LEVEL | I.D. | O.D. | W.P. | P.P. | Min.B.P. | Min.B.R. |
| psi | in. | mm | psi | psi | psi | mm |
| 1500 Grade A | 2 | 68 | 1500 | 2250 | 3750 | 800 |
| 2 1/2 | 84 | 1500 | 2250 | 3750 | 800 | |
| 2000 Grade B | 2 | 68 | 2000 | 3000 | 5000 | 800 |
| 2 1/2 | 84 | 2000 | 3000 | 5000 | 800 | |
| 3 | 97 | 2000 | 3000 | 5000 | 950 | |
| 3 1/2 | 113 | 2000 | 3000 | 5000 | 1000 | |
| 4 | 127 | 2000 | 3000 | 5000 | 1000 | |
| 5 | 157 | 2000 | 3000 | 5000 | 1200 | |
| 6 | 183 | 2000 | 3000 | 5000 | 1300 | |
| 4000 Grade C | 2 | 72 | 4000 | 6000 | 10000 | 800 |
| 2 1/2 | 87 | 4000 | 6000 | 10000 | 800 | |
| 3 | 102 | 4000 | 6000 | 10000 | 1000 | |
| 3 1/2 | 119 | 4000 | 6000 | 10000 | 1200 | |
| 4 | 132 | 4000 | 6000 | 10000 | 1200 | |
| 5 | 162 | 4000 | 6000 | 10000 | 1400 | |
| 6 | 194 | 4000 | 6000 | 10000 | 1500 | |
| 5000 D级Grade D | 2 | 75 | 5000 | 7500 | 12500 | 800 |
| 2 1/2 | 90 | 5000 | 7500 | 12500 | 800 | |
| 3 | 104 | 5000 | 7500 | 12500 | 1000 | |
| 3 1/2 | 121 | 5000 | 7500 | 12500 | 1200 | |
| 4 | 134 | 5000 | 7500 | 12500 | 1200 | |
| 5 | 167 | 5000 | 7500 | 12500 | 1400 | |
| 6 | 196 | 5000 | 7500 | 12500 | 1600 | |
| 7500 Grade E | 2 | 77 | 7500 | 11250 | 18750 | 900 |
| 2 1/2 | 94 | 7500 | 11250 | 18750 | 1000 | |
| 3 | 110 | 7500 | 11250 | 18750 | 1000 | |
| 3 1/2 | 128 | 7500 | 11250 | 18750 | 1200 | |
| 4 | 150 | 7500 | 11250 | 18750 | 1400 | |
| 5 | 183 | 7500 | 11250 | 18750 | 1600 | |
| 6 | 212 | 7500 | 11250 | 18750 | 1600 |
